[ INDIVIDUAL COMPONENT // COOLING ]
Noctua NH-U14S
165 mm installed height; NF-A15 PWM 140×150 mm fan.
IDENTIFICATION: Match complete model, suffix, revision and bundle before installation. Related variants can differ in dimensions, brackets, wiring, connector, and operating limits.
Manufacturer specifications
| Catalog subcategory | Tower And Dual Tower Air Coolers |
|---|---|
| Exact model | Noctua NH-U14S |
| Published specifications | 165 mm installed height; NF-A15 PWM 140×150 mm fan. |
| Compatibility and mounting | Socket kit and board clearance are model-specific; confirm 165 mm case limit. |
| Connector and electrical limitations | NF-A15 12 V 4-pin PWM; check label/spec and header limit, especially with second fan. |
Safe installation and maintenance
Disconnect AC power before mounting. Use only the exact socket-specific kit and manufacturer tightening sequence; measure case/board clearance. If cooler is removed, clean both surfaces and renew compound before reinstalling.
- Follow the exact manufacturer manual for this model and host; do not interchange similar-looking parts or hardware.
- After service, verify pump/fan operation and temperature behavior under monitored conditions before normal workload.
Manufacturer source
- www.noctua.at — Noctua NH-U14S product informationManufacturer specifications; verify current revision-specific manual and compatibility details before installation.
This static catalog entry is an identification aid, not a compatibility guarantee; ratings can vary by revision or SKU.
