[ IDENTIFIED ENCLOSURE // OPTIPLEX 7010 MICRO FORM FACTOR BUSINESS PC ]
Dell OptiPlex 7010 Micro
182 × 178 × 36 mm (H × D × W); external DC power supply and mount are excluded from bare chassis envelope.
VARIANT / ARCHIVAL CAVEAT: 7010 Micro is distinct from 7010 SFF/Tower and previous 7010 USFF. Check chassis label/service tag and 2023 maintenance guide for rear I/O and adapter revision.
Mechanical specifications and fit
| Catalog identity | OptiPlex 7010 Micro Form Factor business PC |
|---|---|
| Dimensions and clearances | 182 × 178 × 36 mm (H × D × W); external DC power supply and mount are excluded from bare chassis envelope. |
| Drive bays / mounts | One 2.5-inch SATA position and M.2 2230/2280 storage depending on shipped build; internal bracket/cable required for SATA. |
| Board, system and compatibility | Proprietary OptiPlex Micro board and external adapter; optional mounting sleeves and stands are model-specific and not compatible by name alone. |
| Revision / identification | 7010 Micro is distinct from 7010 SFF/Tower and previous 7010 USFF. Check chassis label/service tag and 2023 maintenance guide for rear I/O and adapter revision. |
Preservation and installation notes
7010 Micro is distinct from 7010 SFF/Tower and previous 7010 USFF. Check chassis label/service tag and 2023 maintenance guide for rear I/O and adapter revision.
Proprietary OptiPlex Micro board and external adapter; optional mounting sleeves and stands are model-specific and not compatible by name alone.
- Capture the complete model/SKU, serial/date label, board assembly and bay/backplane/riser identifiers before disassembly; keep matched screws, trays, carriers, feet and cables with the case.
- Check the cited manual's specific build option before transferring hardware. Published maximum GPU, drive, fan or radiator capacity may not be simultaneous when a removable cage or alternative riser occupies that volume.
- For rack and vintage systems, preserve the exact rails, shields, doors, brackets and model-specific safety instructions; do not infer compatibility from a familiar brand or physical connector shape.
Manufacturer manuals and archival sources
- Dell OptiPlex 7010 Micro official support/specificationsPrimary manufacturer or model-specific technical/manual reference used for the identification and mechanical data above.
- Dell OptiPlex 7010 Micro manuals and documentsSecond product manual, manufacturer resource or established technical archive; choose the exact regional SKU and revision. Original page is gone; this is the Internet Archive’s copy.
When exact dimensions depend on configuration, the text says so; verify the measured specimen before making a fit or restoration decision.
